| Configuration | Desktop |
|---|---|
| Color / Black & White | Color |
| Technology | Laser |
| Toner Type | Dry, single component |
| Black & White Speed | 42 ppm |
| Color Print Speed | 42 ppm |
| Maximum Monthly Volume | 20,000 prints |
| Maximum Duty Cycle | 150,000 prints |
| First Print Speed | Black: 10 sec or less, Full-Color: 15 sec or less |
| Warm-Up Time | 46 seconds |
| Recovery from Sleep Mode | 46 seconds |
| Print Resolution | Up to 1200 x 1200 dpi |
| Standard Paper Capacity | 1 x 550-Sheet Tray + 100-Sheet Bypass Tray |
| Maximum Paper Capacity | 2,300 sheets |
| Output Capacity | 500 sheets |
| Supported Paper Sizes | Paper Trays: 3.9" x 5.8" - 8.5" x 14.0" Bypass Tray: 2.8" x 5.0" - 8.5" x 49.6" |
| Supported Paper Weights | Standard and Optional Trays: 14-59 lb. Bond/120 lb. Index (52-220 g/m2) Bypass Tray: 14-69 lb. Bond/140 lb. Index (52-256 g/m2) Duplex: 16-44 lb. Bond/90 lb. Index (60-163 g/m2) |
| Supported Paper Types | Plain, Recycled, Thin, Thick, OHP (Transparency), Letterhead, Preprinted, Label, Glossy, Coated and Envelopes |
| Duplexing | Automatic (standard) |
| Power Requirements | 120 V, 60Hz, 12A |
| Power Consumption | Operating: 826 W Sleep: 0.53 W |
| Dimensions W x D x H | 17.48" x 25.91" x 19.29" (444 x 658 x 490 mm) |
| Weight | 126 lbs. (57 kg) |
Locking Paper Feed Unit PB1020TE (1 x 550 Sheets)
ID: 407936
- A locking paper tray.
- Paper Sizes: Up to 8.5" x 14".
- Paper Weights: Up to 59 lb. Bond/120 lb. bond index
- Dimensions: 17.48” x 23.22” x 5.51” (444 x 590 x 140 mm)
- Weight: 26.4 lbs (12 kg)
Notes:
- Up to 3 Paper Feed Units may be added to the mainframe for a maximum paper capacity of 2,300 sheets.
- Caster Table Type C is required when the maximum of three optional Paper Feed Units are installed.
- Paper Feed Unit PB1020TE cannot be installed with Tall Cabinet Type C430.
Caster Table Type C
ID: 406755
- Provides a platform with wheels to easily move the device.
- Must be added when the device is configured with 3 optional Paper Feed Units.
- Weight: 21.1 lbs. (9.6 kg)
- W x D x H (inches): 21.7 x 21.6 x 5.04
- W x D x H (mm): 551 x 549 x 128
Notes:
- 1. Caster Table Type C cannot be installed with the SP C440DN base unit, Tall Cabinet Type C430 or Medium Cabinet Type C430.
- 2. Caster Table Type C can only be installed when the system is configured with three optional 550-sheet Paper Feed Units. If three paper feed units are not added then this option cannot be added to your configuration.
Medium Cabinet Type C430
ID: 52111
- Raises the SP C440DN to a comfortable height for a floor-standing configuration when the printer is configured with either one or two optional 550-sheet Paper Feed Units.
- Weight: 29.5 lbs. (13.4 kg)
- W x D x H (inches): 17.5 x 22.8 x 11
- W x D x H (mm): 445 x 579 x 279
Notes:
- 1. Medium Cabinet Type C430 cannot be installed with the SP C440DN base unit, Tall Cabinet Type C430 or Caster Table Type C.
- 2. Medium Cabinet Type C430 can only be installed when the system is configured with either one or two optional 550-sheet Paper Feed Units. If one or two optional paper feed units are not added then this option cannot be added to your configuration.
Paper Feed Unit PB1020
ID: 406681
- Provides an additional 550 sheets.
- Paper sizes up to 8.5" x 14".
- Paper weights up to 59 lb. Bond/120 lb. Index.
- Note: Up to 3 Paper Feed Units may be added to the mainframe for a maximum paper capacity of 2,300 sheets.
- Weight: 26.4 lbs. (12 kg)
- W x D x H (inches): 17.48 x 23.22 x 5.51
- W x D x H (mm): 444 x 590 x 140
Notes:
- 1. Caster Table Type C is required when the maximum of three optional Paper Feed Units are installed.
- 2. Paper Feed Unit PB1020 cannot be installed with Tall Cabinet Type C430.
Tall Cabinet Type C430
ID: 52121
- Raises the SP C440DN base unit to a comfortable height for a floor-standing configuration.
- Weight: 40.6 lbs. (18.4 kg)
- W x D x H (inches): 17.5 x 22.8 x 19.7
- W x D x H (mm): 445 x 579 x 500
Notes:
- Tall Cabinet Type C430 cannot be installed with Paper Feed Unit PB1020, Medium Cabinet Type C430 or Caster Table Type C.
