SP C435DN

Caster Table Type C

ID: 406755

• Provides a platform with wheels to easily move the device.
• Must be added when the device is configured with 3 optional Paper Feed Units.
• Weight: 21.1 lbs. (9.6 kg)
• W x D x H (inches): 21.7 x 21.6 x 5.04
• W x D x H (mm): 551 x 549 x 128

Notes:

• 1. Caster Table Type C cannot be installed with the SP C440DN base unit, Tall Cabinet Type C430 or Medium Cabinet Type C430.
• 2. Caster Table Type C can only be installed when the system is configured with three optional 550-sheet Paper Feed Units. If three paper feed units are not added then this option cannot be added to your configuration.

Medium Cabinet Type C430

ID: 52111

• Raises the SP C440DN to a comfortable height for a floor-standing configuration when the printer is configured with either one or two optional 550-sheet Paper Feed Units.
• Weight: 29.5 lbs. (13.4 kg)
• W x D x H (inches): 17.5 x 22.8 x 11
• W x D x H (mm): 445 x 579 x 279

Notes:

• 1. Medium Cabinet Type C430 cannot be installed with the SP C440DN base unit, Tall Cabinet Type C430 or Caster Table Type C.
• 2. Medium Cabinet Type C430 can only be installed when the system is configured with either one or two optional 550-sheet Paper Feed Units. If one or two optional paper feed units are not added then this option cannot be added to your configuration.

Paper Feed Unit PB1020

ID: 406681

• Provides an additional 550 sheets.
• Paper sizes up to 8.5" x 14".
• Paper weights up to 59 lb. Bond/120 lb. Index.
• Note: Up to 3 Paper Feed Units may be added to the mainframe for a maximum paper capacity of 2,300 sheets.
• Weight: 26.4 lbs. (12 kg)
• W x D x H (inches): 17.48 x 23.22 x 5.51
• W x D x H (mm): 444 x 590 x 140

Notes:

• 1. Caster Table Type C is required when the maximum of three optional Paper Feed Units are installed.
• 2. Paper Feed Unit PB1020 cannot be installed with Tall Cabinet Type C430.

Tall Cabinet Type C430

ID: 52121

• Raises the SP C440DN base unit to a comfortable height for a floor-standing configuration.
• Weight: 40.6 lbs. (18.4 kg)
• W x D x H (inches): 17.5 x 22.8 x 19.7
• W x D x H (mm): 445 x 579 x 500

Notes:

• Tall Cabinet Type C430 cannot be installed with Paper Feed Unit PB1020, Medium Cabinet Type C430 or Caster Table Type C.

Hard Disk Drive Option Type P7

ID: MX407776RA

• The Hard Disk Drive (HDD) enables the printer to store documents for fast, efficient on-demand printing which helps to eliminate the cost and waste associated with pre-printed materials.
• The HDD is required for Locked/Hold/Stored Print.
• Data Overwrite and HDD Encryption are available when the HDD is installed.

IPDS Unit Type P7

ID: 407777

• For use in AS/400 environments.
• Intelligent Printer Data Stream (IPDS). As a "genuine" IPDS solution built on original IBM source code, our IPDS option provides more accurate interpretation of IPDS data. That means less errors and faster file processing than emulations. Plus, as an IBM partner your customers can be assured of fast problem resolution and timely upgrades.

Notes:

• Hard Disk Drive Option Type P7 is required to add this option.

XPS Direct Print Option Type P7

ID: 407781

• This option enables direct printing of XPS format documents.

Embedded HotSpot Option Type S

ID: 415620

• Required to enable HotSpot printing. One year HotSpot printing subscription service.

IEEE 802.11 Interface Unit Type O

ID: 407113

• Allows the main unit to connect to a wireless network. Useful for temporary sites and locations where cabling is impractical.

IEEE1284 Interface Board Type A

ID: 411699

• For environments that require Parallel connectivity.
• Allows device connection with legacy computer equipment.

Notes:

• IEEE1284 Interface Board Type A cannot be installed with IEEE802.11a/g/n Wireless Interface Type M2, File Format Converter Type E or USB Device Server Option Type M12.

USB Device Server Option Type M12A

ID: 418111

• This option can hold an additional IP address, which then enables our MFPs to connect to two different network environments.

Notes:

• USB Device Server Option Type M12A cannot be installed with IEEE1284 Interface Board Type A, IEEE802.11a/g/n Wireless Interface Type M2 or File Format Converter Type E.

ESP S1 Power Filter

ID: ESPS1

• The affordable ESP S1 power filter provides multi-stage power protection for output devices. Our Advanced Technical Support (ATS) recommends the use of Power Protection products to minimize potential electrical interference with products.

Notes:

• ESP S1 Power Filter cannot be installed with the ESP XG-PCS-15D Power Filter.

VM Card Type P7

ID: 407784

• The VM Card enables the installation of embedded software applications.

Notes:

• Hard Disk Drive Option Type P7 is required to add this option.
