| Configuration | Desktop |
|---|---|
| Scanning Element | Flatbed scanner with full color contact image sensor (CIS) |
| Printing Process | Laser beam scanning, color electrophotographic printing with monocomponent toner development 4-drum tandem method |
| Control Panel | LCD panel |
| Color/Black & White | Color |
| Output Speed Copy/Print | 21 ppm B&W and Full-Color; 12 ppm duplex |
| First Page Out Time | 20 seconds or less for both B&W and Full-Color |
| Warm-Up Time | 30 seconds or less (from Energy Saver Mode) |
| Resolution | 1200 x 1200 dpi (scanning) 600 x 600 dpi (printing) |
| System Memory | 256 MB RAM standard/maximum |
| Maximum Copy Quantity | 1-999 |
| Duplexing | Automatic (Standard) |
| Original Type | Sheet/Book/3D Objects |
| Maximum Original Size | Up to 8.5" x 11" (Platen) Up to 8.5" x 14" (ADF) |
| Supported Paper Sizes | Standard Tray and Bypass Tray: Letter (8.5" x 11"), Legal (8.5" x 14"), EXEC (10.5" x 7.25"), Half Letter (5.5" x 8.5"), A4 (8.3" x 11.7"), A5 (5.8" x 8.3"), A6 (4.1" x 5.8"), B5 JIS (7.2" x 10.1"), B6 JIS (5.0" x 7.2"), F (8" x 13"), Foolscap (8.5" x 13"), Folio (8.25" x 13"), 16 Kai (7.6" x 10.5") Envelopes: Com10, Monarch, C5, C6, DL Custom size: Min. 90 mm x 148 mm (3.54" x 5.83"), Max. 216 mm x 356 mm (8.5" x 14.0") Optional Paper Feed Unit: Letter (8.5" x 11"), A4 (8.3" x 11.7") |
| Supported Paper Weights | Standard Tray and Bypass Tray: 16 - 42 lb. Bond/83 lb. Index (60 - 160 g/m²) Duplex: 16 - 24 lb. Bond (60 - 90 g/m²) Optional Paper Feed Unit: 16 - 28 lb. Bond (60 - 105 g/m²) |
| Supported Paper Types | Standard Tray and Bypass Tray: Plain Paper, Middle Thick, Recycle Paper, Envelopes, Thick Paper, Labels, Thin Paper, Color Paper, Prepunched Paper, Letterhead, Bond Paper, Card Stock and Preprinted Paper (Std. Tray only) Optional Paper Feed Unit: Plain Paper, Middle Thick, Recycle Paper, Thick Paper, Thin Paper, Color Paper, Preprinted Paper, Prepunched Paper and Letterhead |
| Standard Paper Capacity | 250-Sheet Paper Tray + 1-Sheet Bypass Tray |
| Maximum Paper Capacity | 500-Sheet Paper Feed Unit (751 sheets maximum) |
| Standard Output Capacity | 150 sheets (face down) |
| Maximum Monthly Volume | 1500 |
| Power Source | 120V, 60Hz |
| Typical Electricity Consumption (TEC) | 1.48 kWh/week |
| Power Consumption | 1,300W or less; 2.4W Energy Saver Mode |
| Energy Star | Certified |
| Safety Regulations | UL60950-1 2nd Edition; CAN/CSA C22.2 No. 60950-1 (c-UL) |
| Dimensions W x D x H | 16.5" x 19.4" x 18.1" (420 x 493 x 460 mm) |
| Weight | 64 lb. (29 kg) (including consumables) |
| Standard Features | Image Density Adjustment (manual only: 5 levels) Copy Mode (Text/Photo/Mixed) Color Balance Adjustment Combine Copy (2-in-1, 4-in-1 via ADF only) Duplex Copy ID Card Copy (2 in 1) Memory Copy Photo Mode Electronic Sorting (collation, ADF only) |
