| Configuration | Desktop |
|---|---|
| Scanning Element | One-Dimensional Solid Scanning Through CCD |
| Printing Process | Dry electrostatic transfer system with dual component development; 4-drum method |
| Control Panel | 10.1" Smart Operation Panel |
| Color/Black & White | Color |
| Output Speed Copy/Print | 42 ppm |
| First Page Out Time | 4.9 seconds (B&W); 6.8 seconds (Color) |
| Warm-Up Time | 66 sec. (from main switch) |
| Recovery Time From Sleep Mode | 8 seconds |
| Resolution | 600 x 600 dpi |
| System Memory | 2 GB |
| Maximum Copy Quantity | Up to 999 |
| Duplexing | Automatic (Standard) |
| Document Feeder Type | Automatic Reversing Document Feeder (ARDF) |
| Automatic Reversing Document Feeder (ARDF) | Standard |
| Document Feeder Capacity | 50 sheets (SPDF) |
| Preset Reduction and Enlargement Ratios | 65%, 78%, 200% |
| Zoom Range | 25% to 400% in 1% increments |
| Exposure Adjustment | Manual and automatic |
| Exposure Glass Size | Up to 8.5" x 14" |
| Maximum Original Size | Up to 8.5" x 14" |
| Supported Paper Sizes | Standard Tray: 5.5" x 8.5" to 8.5" x 11" Optional Trays: 5.5" x 8.5" to 8.5" x 14" Bypass Tray: 5.5" x 8.5" to 8.5" x 14" Duplex Unit: 5.5" x 8.5" to 8.5" x 14" |
| Supported Paper Weights | Standard Trays: 16 – 43 lb. Bond (60 – 163 g/m2) Optional Trays: 16 – 43 lb. Bond (60 – 163 g/m2) Bypass Tray: 16 – 58 lb. Bond (60 – 220 g/m2) Duplex Unit: 16 – 43 lb. Bond (60 – 163 g/m2) |
| Supported Paper Types | Plain, Recycled, Colored, Letterhead, Preprinted, Bond, Card Stock, Special, Coated, Waterproof, Back Copied, Middle Thick, Thick, OHP (Transparency)*, Envelopes*, Label Stock* |
| Standard Paper Capacity | Standard: 250 sheets + 100-sheet Bypass Tray Optional: 500 sheets x 1 or 2 Trays |
| Maximum Paper Capacity | Maximum Capacity 1,350 sheets |
| Standard Output Capacity | Standard: 100 sheets Optional: 200 sheets (total) with One Bin Tray |
| Maximum Monthly Volume | 5000 |
| Power Source | 120V, 60Hz, 15A |
| Typical Electricity Consumption (TEC) | 1.755 kWh/week |
| Power Consumption | Less than 1.3 KW (max.); 0.63 W (Sleep Mode) |
| EPEAT Status | Gold |
| Dimensions W x D x H | 20.1" x 23.1" x 19.9" (510 mm x 588 mm x 505 mm) – includes ARDF and Operation Panel |
| Weight | 99.2 lbs. (45 kg) |
| Standard Features | Document Server, JavaTM, Poster Copy, ID Card Copy, Auto Tray Switch, Auto Start, Auto Off Timer, Energy Saver Timer, Color Balance Adjustment, Color Balance Program, Auto Color Calibration, Combine Copy, Electronic Sort, Photo Mode, Series Copy, Job Programs, User Codes (1,000), Simplified Display, Login/Logout Button, Eco-friendly Indicator |
| Footnotes | *Bypass Tray only. **Typical Electricity Consumption by ENERGY STAR® Program. |
Fax Connection Unit Type M13
ID: 417351
- Enables users to send and receive faxes on a sub MFP via a main center MFP with a fax option.
1 Bin Tray BN1020
ID: 417413
- 100-sheet capacity. Provides additional output tray to separate fax/print output from copy.
MPC305 High Cabinet
ID: 100470FNG
- Raises the base unit to a comfortable height for a floor-standing configuration.
- Weight: 39.7 lbs. (18 kg)
- W x D x H (inches): 19.6 x 20.7 x 23.6
- W x D x H (mm): 498 x 526 x 599
Notes:
- 1. MPC305 High Cabinet cannot be installed with Paper Feed Unit PB1080, MPC305 Low Cabinet, or MPC305 Medium Cabinet.
- 2. MPC305 High Cabinet can only be installed when a main unit is configured without an optional 500-sheet Paper Feed Unit. If one or two optional paper feed units are selected then this option cannot be added to your configuration.
MPC305 Low Cabinet
ID: 100468FNG
- Raises the base unit to a comfortable height for a floor-standing configuration when the printer is configured with two optional 500-sheet Paper Feed Units.
- Weight: 30.8 lbs. (14 kg)
- W x D x H (inches): 19.6 x 20.7 x 11.8
- W x D x H (mm): 498 x 526 x 300
Notes:
- 1. MPC305 Low Cabinet cannot be installed with the base unit, MPC305 Medium Cabinet, or MPC305 High Cabinet.
- 2. MPC305 Low Cabinet can only be installed when the base unit is configured with two optional 500-sheet Paper Feed Units. If two optional paper feed units are not added then this option cannot be added to your configuration.
MPC305 Medium Cabinet
ID: 100469FNG
- Raises the base unit to a comfortable height for a floor-standing configuration when the printer is configured with one optional 500-sheet Paper Feed Unit.
- Weight: 35.3 lbs. (16 kg)
- W x D x H (inches): 19.6 x 20.7 x 17.7
- W x D x H (mm): 498 x 526 x 450
Notes:
- 1. MPC305 Medium Cabinet cannot be installed with the base unit, MPC305 Low Cabinet, or MPC305 High Cabinet.
- 2. MPC305 Medium Cabinet can only be installed when the base unit is configured with one optional 500-sheet Paper Feed Unit. If one optional paper feed unit is not added then this option cannot be added to your configuration.
Paper Feed Unit PB1080
ID: 417426
- Provides an additional 500 sheets.
- Paper sizes up to 8.5" x 14".
- Paper weights up to 44 lb. Bond/90 lb. Index.
- Weight: 23 lbs. (10.4 kg)
- Up to 2 Paper Feed Units may be added to the mainframe for a maximum paper capacity of 1,350 sheets.
- W x D x H (inches): 19.6 x 21.7 x 5.9
- W x D x H (mm): 498 x 551 x 150
Notes:
- Paper Feed Unit PB1080 cannot be installed with MPC305 High Cabinet.
Camera Direct Print Card Type M13
ID: 417356
- Allows users to connect a PictBridge compatible digital still camera directly to the printer without a PC, enabling direct, on the spot printing.
Embedded HotSpot Option Type S
ID: 415620
- Required to enable HotSpot printing. One year HotSpot printing subscription service.
File Format Converter Type E
ID: 414007
- Required to convert formats and drag to desktop documents stored via Copy or Print mode.
Notes:
- File Format Converter Type E cannot be installed with IEEE1284 Interface Board Type A, IEEE802.11a/g/n Wireless Interface Type M2 or or USB Device Server Option Type M12.
IEEE1284 Interface Board Type A
ID: 411699
- For environments that require Parallel connectivity.
- Allows device connection with legacy computer equipment.
Notes:
- IEEE1284 Interface Board Type A cannot be installed with IEEE802.11a/g/n Wireless Interface Type M2, File Format Converter Type E or USB Device Server Option Type M12.
IEEE802.11a/g/n Wireless Interface Type M2
ID: 416572
- This option allows you to connect the device wirelessly to the LAN.
Notes:
- IEEE802.11a/g/n Wireless Interface Type M2 cannot be installed with IEEE1284 Interface Board Type A, File Format Converter Type E or USB Device Server Option Type M12.
OCR Unit Type M13
ID: 417430
- This function embeds invisible text on scanned images of PDF and enables users to search PDF files by arbitrary keywords. Searchable PDF files can be sent to email, folders, and external media (USB/SD Card).
Unicode Font Package for SAP 1 Device License
ID: 413009
- Unicode Font Package for SAP - 1 seat license.
USB Device Server Option Type M12A
ID: 418111
- This option can hold an additional IP address, which then enables our MFPs to connect to two different network environments.
Notes:
- USB Device Server Option Type M12A cannot be installed with IEEE1284 Interface Board Type A, IEEE802.11a/g/n Wireless Interface Type M2 or File Format Converter Type E.
XPS Direct Print Option Type M13
ID: 417357
- This option enables direct printing of XPS format documents.
Copy Data Security Unit Type G
ID: 416391
- Prevents unauthorized copying of confidential documents.
Data Overwrite Security Unit Type I
ID: 416372
- This is an ISO 15408 Certified version of DOSS that overwrites Copy, Print, Scanner, and Fax latent data. Mainframe is targeted to be ISO 15408 certified in January 2016.
ESP AC1 Power Filter
ID: ESPAC1
- The affordable ESP AC1 power filter provides multi-stage overload protection for output devices. Our Advanced Technical Support (ATS) recommends the use of overload protection products to minimize potential electrical interference with products.
Notes:
- The ESP AC1 power filter can not be installed with the ESP XG-PCS-15D.
ESP XG-PCS-15D Power Filter
ID: 006428MIU
- The ESP XG-PCS-15D power filter provides multi-stage power protection as well as line conditioning. Our Advanced Technical Support (ATS) recommends the use of Power Protection products to minimize potential electrical interference with products.
Notes:
- ESP XG-PCS-15D Power Filter cannot be installed with the ESP S1 Power Filter.
External USB Keyboard (No Bracket)
ID: 100266FNG
- External keyboard for inputting data with either SDK applications or embedded applications.
Notes:
- 1. External Keyboard Bracket Type M19 is required for this option.
- 2. External USB Keyboard (No Bracket) cannot be installed with the NFC Card Reader Type M19.
NFC Card Reader Type M13
ID: 417412
- Enables users to log into and authenticate to the MFP with a programmed access card.
- Does not support Java SDK applications.
Optional Counter Interface Unit Type M12
ID: 417111
- 20-Pin interface used to attach external key counter or key card device.
