| Configuration | Console |
|---|---|
| Printing Process | 4-Drum Method |
| Control Panel | 10.1" Smart Operation Panel |
| Color/Black & White | Color |
| Output Speed Copy/Print | 30 ppm B&W & FC (LTR) |
| First Page Out Time | 7.1/4.6 seconds |
| Warm-Up Time | 25 seconds |
| Recovery Time From Sleep Mode | 6.9 seconds |
| Resolution | 600 dpi |
| System Memory | 2 GB RAM/250GB HDD Standard & 4GB RAM/250 GB HDD Option |
| Maximum Copy Quantity | Up to 999 copies |
| Duplexing | Automatic (Standard) |
| Single Pass Document Feeder (SPDF) | Original Capacity: 220 sheets Original Size: 5.5" x 8.5" – 11" x 17" (A5-A3) Paper Weight: Simplex: 11 - 34 lb. Bond (40 - 128 g/m2) Duplex: 14 -34 lb. Bond (52 - 128 g/m2) |
| Zoom Range | 25% - 400% in 1% increments |
| Supported Paper Sizes | 1st Paper Tray: 8.5" x 11" (A4) 2nd Paper Tray: 5.5" x 8.5" - 12" x 18" (A6-A3), Envelopes |
| Supported Paper Weights | Standard Trays: 16 - 80 lb. Bond/166 lb. Index (60 - 300 g/m2) Duplex Unit: 14 -68 lb. Bond / 142 lb. Index (52 - 256 g/m2) |
| Supported Paper Types | Plain, Recycled, Special Paper 1-3, Letterhead, Cardstock, Preprinted Paper, Bond Paper, High-Gloss Coated Paper, Color Paper, Envelopes, Coated, Labels* & OHP* |
| Standard Paper Capacity | 2,200 sheets |
| Maximum Paper Capacity | 2,200 sheets |
| Standard Output Capacity | 500 sheets |
| Maximum Output Capacity | 1,625 sheets (with options) |
| Maximum Monthly Volume | 20000 |
| Power Source | 120V - 127V, 60Hz, 15A |
| Typical Electricity Consumption (TEC) | 1.2 kWh/week |
| Power Consumption | 1,584W or less; Sleep Mode: 0.8W |
| EPEAT Status | Gold |
| Dimensions W x D x H | 26.3" x 29.1" x 47.5" (668 x738 x 1205mm) (Includes SPDF and Two-Tray Paper Bank) |
| Weight | 223 lbs. (101 kg) |
| Footnotes | *Bypass Tray Only **Typical Electricity Consumption by ENERGY STAR Qualified Imaging Equipment Test Procedure |
USB Device Server Option Type M19A
ID: 418105
- An interface board for adding an extra Ethernet port. If you install the USB Device Server Option, you can connect two Ethernet cables simultaneously: one to the machine's Gigabit Ethernet port and one to the Gigabit Ethernet port of USB Device Server Option. An IP address can be assigned to each connection and you can use one machine to print from different network segments.
Notes:
- USB Device Server Option Type M19A cannot be installed with IEEE 1284 Interface Board Type M19, IEEE 802.11a/g/n Interface Unit Type M19, File Format Converter Type M19, or Extended USB Board Type M19.
