Configuration | Console |
---|---|
Scanning Element | One-Dimensional Solid Scanning Through CCD |
Printing Process | Single Laser Beam Scanning & Electrophotographic Printing |
Toner Type | Dry, Dual Component |
Control Panel | 10.1" Smart Operation Panel |
Color/Black & White | Black & White |
Output Speed Copy/Print | 35 ppm |
First Page Out Time | 4.3 Seconds |
Warm-Up Time | Less than 24 seconds |
Recovery Time From Sleep Mode | 7.9 seconds |
Resolution | 600 x 600 dpi |
System Memory | 2 GB RAM + 320 GB HDD (Shared) |
Maximum Copy Quantity | Up to 999 |
Document Feeder Type | Automatic Reversing Document Feeder (ARDF) version or Single Pass Document Feeder (SPDF) version |
Document Feeder Original Size | 5.5" x 8.5" - 11" x 17" (A5 - A3) |
Document Feeder Paper Weight | Simplex: 11 - 34 lb. Bond (40 - 128 g/m2) Duplex: 14 - 34 lb. Bond (52 - 128 g/m2) |
Document Feeder Capacity | ARDF: 100 sheets, SPDF: 220 sheets |
Preset Reduction and Enlargement Ratios | Ratios 25%, 50%, 65%, 73%, 78%, 85%, 93%, 100%, 121%, 129%, 155%, 200%, 400% |
Zoom Range | 25% to 400% in 1% increments |
Original Type | Book/Sheet/Object |
Maximum Original Size | Up to 11" x 17" |
Supported Paper Sizes | Tray 1 & 2: 5.5" x 8.5" - 11" x 17" (A6 - A3) Bypass Tray: 5.5" x 8.5" - 12" x 18" (A6 - A3) |
Supported Paper Weights | Tray 1 & 2: 16 - 80 lb. Bond (60 - 300 g/m2) Bypass: 14 - 80 lb. Bond (52 - 300 g/m2) Duplex: 14 - 68 lb. Bond (52 - 256 g/m2) |
Supported Paper Types | Plain, Recycled, Colored, Special, Letterhead, Preprinted, Pre-punched, Bond, Cardstock, Envelope, OHP*, Label* |
Standard Paper Capacity | 1,200 sheets (550 sheets x 2 trays, and 100-Sheet Bypass Tray) |
Maximum Paper Capacity | 2,200 sheets |
Standard Output Capacity | 500 sheets |
Maximum Output Capacity | 1,625 sheets (Bridge Unit + 1 Bin + 1,000-Sheet Finisher) |
Maximum Monthly Volume | 30000 |
Power Source | 120V/60Hz/12A |
Typical Electricity Consumption (TEC) | 1.4 kWh/week |
Power Consumption | Less than 1.6kW |
EPEAT Status | Gold |
Dimensions W x D x H | 23.1" x 26.9" x 35.9" (587 x 684 x 913mm) w/ARDF 23.1" x 26.9" x 37.9" (587 x 684 x 913mm) w/SPDF |
Weight | 156.5 lbs. (71) kg w/ARDF 168.6 lbs. (76.5 kg) w/SPDF |
Standard Features | Auto Paper Select, Auto Tray Switch, Auto Image Density, Auto Text & Photo Separation, Auto Start, Auto Off Timer, Booklet/Magazine Copy, Shift/Erase/Margin Adjustment, Combine (Layout), Cover/Chapter/Slip Sheets Insertion, Image Rotation, Document Server (3,000 File Capacity) with Folder Management and Password Protection, Web Browser, Duplex, Electronic/Rotate Sorting, 8 Job Presets, 25 Job Programs, Negative/Positive, Sample Copy, Series Copy, Simplified Display, 1,000 User Codes, Stamps/Numbering, Interrupt Copy, Login/Logout Button, System Reset Timer, Import/Export of Preference Settings, Eco-Friendly Indicator, Centralized Address Book Management |
