Configuration | Console |
---|---|
Printing Process | 4-drum dry electrostatic transfer system with internal transfer belt |
Control Panel | 10.1" Smart Operation Panel |
Color/Black & White | Color |
Output Speed Copy/Print | 65 ppm |
First Page Out Time | Color: 7.5 seconds/B&W: 5.5 seconds |
Warm-Up Time | 45 seconds |
Resolution | Copy: 600x600 dpi |
System Memory | 4 GB RAM 640 GB HDD (320 GB x 2) |
Maximum Copy Quantity | Up to 9,999 copies |
Duplexing | Automatic (Standard) |
Document Feeder Type | Single Pass Duplex Feeder (SPDF) |
Zoom Range | 25% to 400% in 1% increments |
Supported Paper Sizes | SRA3+, SRA3, A3, Letter, Legal, Ledger, A5, A6, B4, B5, B6 |
Supported Paper Weights | Trays: 52 - 256 g/m2 Bypass: 52 - 300 g/m2 Duplex: 52 - 256 g/m2 |
Supported Paper Types | Plain, Recycled, Color, Special Paper, Letterhead, Preprinted, Prepunched, Bond, Cardstock |
Standard Paper Capacity | 3,700 sheets |
Maximum Paper Capacity | 8,100 sheets |
Standard Output Capacity | 500 sheets |
Maximum Output Capacity | 3,500 sheets |
Power Source | 120V - 127V / 16A, 60Hz |
Typical Electricity Consumption (TEC) | 1.217 kWh/week |
Power Consumption | Maximum: Less than 1,920 W Sleep: 0.62 W |
Energy Star | Certified |
EPEAT Status | Gold |
Dimensions W x D x H | 29.5" x 34.7" x 48.3" (750 x 880 x 1,225 mm) |
Weight | 551 lbs (250 kg) |
Fax Option Type M42
ID: 418209
- Installation required to enable fax services: 33.6Kbps, approximately 2 Second Transmission Speed, Standard JBIG. Standard 320 Pages Memory. Includes standard Internet Fax (T.37), LAN Fax, IP-Fax (T.38), Fax Forwarding to Email & Paperless Fax function.
Memory Unit Type M26 64 MB
ID: 417695
- Memory expansion, which provides additional 64 MB memory for fascimile functions.
Notes:
- Fax Option Type M42 must be selected to add this option.
Booklet Finisher SR4160
ID: 418180
- The 2,000-sheet Booklet Finisher allows thick documents to be professionally finished as paginated, duplexed, saddle-stitched folded booklets.
- Up to 20 sheets can be saddle-stitched.
- It also offers 65-sheet, multi-position stapling, mixed sized stapling, optional hole-punching and shift-sort collating.
- Weight: 127.9 lbs. (58 kg)
- W × D × H (inches): 25.87 × 28.74 × 38.59
- W × D × H (mm): 657 × 730 × 980
Notes:
- Booklet Finisher SR4160 cannot be installed with Copy Tray Type 9002, Finisher SR4150 or any related options.
Cooling Fan Unit Type M26
ID: 417677
- Prevents paper bricking.
- Optional cooling fan for Finisher SR4120 and Booklet Finisher SR4130.
Notes:
- This option cannot be installed with Finisher SR4110.
Copy Tray Type M42
ID: 418184
- The 500-sheet Copy Tray is the system's most basic exit tray for printed or copied output. Select the Copy Tray if you do not require advanced finishing including stapling, hole punching, folding or booklet making.
- When configured with this option, output is delivered face down in a neat stack.
- Weight: 4.85 lbs. (2.2 kg)
- W × D × H (inches): 13.78 × 20.2 × 7.56
- W × D × H (mm): 350 × 513 × 192
Notes:
- Copy Tray Type M42 cannot be installed with Cover Interposer Tray CI4050, Multi-Fold Unit FD4010, Multi-Fold Unit FD4020, Finisher SR4150, Finisher SR4140, Booklet Finisher SR4160, Mail Box CS4010 or any related options.
Cover Interposer Tray CI4050
ID: 418189
- Compatible with Finisher SR4140 only.
- Dual Cover Interposer that allows pre-printed covers and inserts to be easily fed into the finishing workflow at the touch of a button. This option eliminates the need for time-consuming off-line manual insertion and reduces the wear and tear on originals.
- Weight: 99.21 lbs. (45 kg)
- W × D × H (inches): 19.69 × 28.74 × 50
- W × D × H (mm): 500 × 730 × 1,270
Notes:
- 1. Finisher SR4140 must be selected to add this option.
- 2. Cover Interposer Tray CI4050 cannot be installed with Multi-Fold Unit FD4010, Copy Tray Type M42, Finisher SR4150, Booklet Finisher SR4160 or any related options.
Finisher SR4140
ID: 418183
- This 3,000-sheet Finisher is ideal for offices that produce collated and stapled sets of documents. It offers 100-sheet, multi-position stapling, mixed sized stapling, optional hole-punching and shift‑sort collating.
- Weight: 169.8 lbs. (77 kg)
- W × D × H (inches): 31.73 × 28.74 × 38.58
- W × D × H (mm): 806 × 730 × 980
Notes:
- Finisher SR4140 cannot be installed with Copy Tray Type M42, Finisher SR4150, Booklet Finisher SR4160, Mail Box CS4010 or any related options.
Finisher SR4150
ID: 418178
- This 3,000-sheet Finisher is ideal for offices that produce collated and stapled sets of documents. It offers 65-sheet, multi-position stapling, mixed sized stapling, optional hole-punching and shift-sort collating.
- Weight: 83.8 lbs. (38 kg)
- W × D × H (inches): 25.87 × 28.74 × 38.58
- W × D × H (mm): 657 × 730 × 980
Notes:
- Finisher SR4150 cannot be installed with Copy Tray Type 9002, Booklet Finisher SR4160 or any related options.
Mail Box CS4010
ID: 416633
- The 9-Bin Mailbox offers workgroups the ability to separate and stack document output to designated bins directly from the print driver. This option helps keep workflows streamlined and organized.
- Weight: 33 lbs. (15 kg)
- W x D x H (inches): 21.26 x 23.62 x 25.98
- W x D x H (mm): 540 x 600 x 660
Notes:
- 1. One of the following finishers is required: SR4150 or Booklet Finisher SR4160.
- 2. Mail Box CS4010 cannot be installed with Copy Tray Type 9002
Multi-Fold Unit FD4010
ID: 418187
- Provides automatic inline document folding with the ability to deliver folded output in four different patterns; Z‑Fold, Half‑Fold, Letter Fold‑In (Tri‑Fold) and Letter Fold-Out (Tri‑Fold). The Multi-Folding Unit is ideal for companies that want to produce professionally finished documents such as newsletters, brochures, menus and marketing materials in-house.
- Power Requirements: 120V, 60Hz, 15A
- Weight: 99.21 lbs. (45 kg)
- W × D × H (inches): 8.23 × 28.74 × 38.58
- W × D × H (mm): 209 × 730 × 980
Notes:
- 1. Finisher SR4150, Finisher SR4140 or Booklet Finisher SR4160 must be selected to add this option.
- 2. Multi-Fold Unit FD4010 cannot be installed with Cover Interposer Tray CI4050, Multi-Fold Unit FD4020, Copy Tray Type M42 or any related options.
Multi-Fold Unit FD4020
ID: 418185
- Provides automatic inline document folding with the ability to deliver folded output in six different patterns; Half-Fold, Letter Fold‑In (Tri-Fold), Letter Fold-Out (Tri-Fold), Gate-Fold, Double Parallel Fold (Four-Fold) and Z-Fold. The Multi-Folding Unit is ideal for companies that want to produce professionally finished documents such as newsletters, brochures, menus and marketing materials in-house.
- Power Requirements: 120V, 60Hz, 15A
- Weight: 202.82 lbs. (92 kg)
- W × D × H (inches): 18.5 × 27.74 × 38.58
- W × D × H (mm): 470 × 705 × 980
Notes:
- 1. Finisher SR4150 or Booklet Finisher SR4160 must be selected to add this option.
- 2. Multi-Fold Unit FD4020 cannot be installed with Copy Tray Type 9002 or any related options.
Output Jogger Unit Type M25
ID: 417630
- Aligns and stacks output delivered to Finisher SR4150 or Booklet Finisher SR4160.
Punch Unit PU5050 NA
ID: 418201
- Optional 2/3 hole punching unit for Finisher SR4140.
Notes:
- 1. Finisher SR4140 must be selected to add this option.
- 2. Punch Unit PU5050 NA cannot be installed with Finisher SR4150, Booklet Finisher SR4160 or any related options.
Punch Unit PU3090 NA
ID: 418332
- Optional hole punching for the Finisher SR3280.
- Supports paper sizes up to 11" x 17".
11" x 17"/A3 Tray Unit Type M26
ID: 417883
- Enables the feeding of 11" x 17"/A3 paper from standard Tandem Tray 1, which is normally fixed for 8.5" x 11"/A4.
- Paper Capacity up to 1,000 sheets.
- Paper Weights up to 68 lb. Bond/256 g/m<sup>2</sup>.
LCIT RT4060
ID: 418190
- Provides an additional 4,000 sheets.
- Paper sizes up to 8.5" x 11"/A4.
- Paper weights up to 58 lb. Bond/216 g/m2.
- Weight: 47.0 lbs. (21.3 kg)
- W × D × H (inches): 13.86 × 21.26 × 24.61
- W × D × H (mm): 352 × 540 × 625
Notes:
- LCIT RT4060 cannot be installed with LCIT RT4070.
LCIT RT4070
ID: 418204
- Provides an additional 2,200 sheets.
- Paper sizes up to 13" x 19.2".
- Paper weights up to 80 lb. Bond/300g/m2.
- Weight: 183.0 lbs. (83 kg)
- W × D × H (inches): 34.2 × 28.74 × 25.9
- W × D × H (mm): 869 × 730 × 658
Notes:
- LCIT RT4070 cannot be installed with LCIT RT4060.
Tab Sheet Holder Type M2
ID: 416642
- Allows users to set up and print on tabs to separate chapters within the document, eliminating the manual collation of document sets.
- Can be used in either Tray 2 or Tray 3, but not both.
Small Paper Feeding Unit Type M37
ID: 418367
- Optional insert for the Single Pass Document Feeder facilitates scanning small documents in sizes from 3.0" x 4.1" to 5.8" x 8.5".
IPDS Unit Type M42
ID: 418198
- For use in AS/400 environments.
- As a genuine Intelligent Printer Data Stream (IPDS) solution built on original IBM source code, our IPDS option provides more accurate interpretation of IPDS data. That means less errors and faster file processing than emulations. Plus, as an IBM partner your customers can be assured of fast problem resolution and timely upgrades.
PostScript3 Unit Type M42
ID: 418192
- Genuine Adobe® PostScript®3™. Recommended for printing more complex color and PDF files.
- The IM C6500 and IM C8000 come with standard PostScript3 and PDF Direct Print Emulation. This option is available for customers who require True Adobe® workflows like Photoshop®, Illustrator® and PDF/X as well as additional font support. When enabled on the MFP, the standard PostScript3 Emulation will be disabled.
IEEE 802.11a/g/n Interface Unit Type M19
ID: 417493
- This option allows you to connect the device to an IEEE 802.11 a/b/g/n wireless LAN.
OCR Unit Type M13
ID: 417430
- This function embeds invisible text on scanned images of PDF and enables users to search PDF files by arbitrary keywords. Searchable PDF files can be sent to email, folders, and external media (USB/SD Card).
Page Keeper Type M37
ID: 418368
- A multi-feed detection sensor that automatically stops a scanning job if more than one page is fed through the SPDF.
- Ideal for environments that rely on scanning workflows and often scan mixed sized originals.
VM Card Type M37
ID: 418410
- ONLY required to support any embedded software app that is developed on SDK-J (i.e. Java).
Notes:
- 1. Memory Unit Type M37 4GB must be selected to add this option.
- 2. If the embedded software app is developed on the SmartSDK (i.e. full-native Android), then the VM Card option and Memory options are NOT required.
Optional Counter Interface Unit Type M12
ID: 417111
- 20-Pin interface used to attach external key counter or key card device.
Smart Card Reader Built-in Unit Type M19
ID: 417595
- For use with Ricoh & third party software solutions. The smart card reader and its cable will be covered inside the mainframe when this option is attached. Not all card readers may be supported.
