| Configuration | Desktop |
|---|---|
| Control Panel | 10.1" Smart Operation Panel |
| Color/Black & White | Black & White |
| Output Speed Copy/Print | 37 ppm |
| First Page Out Time | Less than 6 seconds |
| Warm-Up Time | 24 seconds |
| Resolution | 1200 x 1200 dpi |
| System Memory | 2 GB RAM/ 320 GB HDD |
| Maximum Copy Quantity | Up to 999 copies |
| Document Feeder Type | Single Pass Document Feeder (SPDF) |
| Single Pass Document Feeder (SPDF) | 50 sheets |
| Zoom Range | 25% to 400% in 1% increments |
| Supported Paper Sizes | Standard paper tray(s): 5.5" x 8.5" - 8.5" x 14" (A6-A4, B6-B5) Optional paper tray(s): 5.5" x 8.5" - 8.5" x 14" (A6-A4, B6-B5) Bypass tray: 5.5" x 8.5" - 8.5" x 14" (A6-A4, B6-B5) Custom Sizes - Width: 2.36" - 8.5" (60 - 216 mm), Length: 5.0" - 35.43" (127 - 900 mm) |
| Supported Paper Weights | Trays: 14 - 58 lb. Bond (52 - 220 g/m²) Bypass: 14 - 68 lb. Bond (52 - 256 g/m²) Duplex: 14 - 43 lb. Bond (52 - 162 g/m²) |
| Supported Paper Types | Plain, Recycled, Special, Colored, Letterhead, Cardstock, Pre-printed, Bond, Coated, Envelope, Label, OHP |
| Standard Paper Capacity | 500 sheets |
| Maximum Paper Capacity | 2,100 sheets |
| Standard Output Capacity | 250 sheets |
| Power Source | 120V - 127V/12A 60Hz |
| Typical Electricity Consumption (TEC) | 0.461 kWh/week TEC value is measured based on the ENERGY STAR Ver.3.0 test method. |
| Power Consumption | Maximum: Less than 1,380W Operation: 566 W Ready: 91 W Sleep: 0.7 W |
| ENERGY STAR® | Certified |
| EPEAT Status | Silver |
| Dimensions W x D x H | 18.7" x 17.4" x 20.1" (476 mm x 442 mm x 510mm) |
| Weight | 67.24 lbs. (30.5 kg) |
Offline Stapler Type M34
ID: 418093
- Optional offline stapler located on the side of the system providing walk-up users with the ability to conveniently staple printed output up to 20 sheets. The stapler can staple 1,000 times without reloading.
- W x D x H (inches): 2.7 x 3.5 x 2.6
- W x D x H (mm): 69 x 89 x 66
Caster Table Type M34
ID: 52007
- The caster table must be added to the configuration when three optional paper feed units are installed. It provides a platform with wheels to easily move the device.
Medium Cabinet Type P
ID: 52005
- Raises the height of the system while providing businesses with a convenient option for the storage of supplies and paper.
- Can only be configured with either one or two optional paper feed units.
- Weight: 35.3 lbs. (16 kg)
- W x D x H (inches): 14.6 x 15.4 x 11.2
- W x D x H (mm): 371 x 391 x 284
Paper Feed Unit PB1110
ID: 418080
- Provides an additional 250 sheets.
- Paper sizes up to 8.5" x 14".
- Paper weights up to 14 lb. Bond/120 lb. Index.
- Weight: 10.58 lbs. (4.8 kg)
- W x D x H (inches): 14.6 x 15.5 x 3.8
- W x D x H (mm): 371 x 394 x 97
Paper Feed Unit PB1120
ID: 418081
- Provides an additional 500 sheets.
- Paper sizes up to 8.5" x 14".
- Paper weights up to 14 lb. Bond/120 lb. Index.
- Weight: 12.13 lbs. (5.5 kg)
- W x D x H (inches): 14.6 x 15.5 x 4.9
- W x D x H (mm): 371 x 394 x 124
Notes:
- Caster Table Type M34 is required when three optional paper feed units are installed.
Tall Cabinet Type Q
ID: 52006
- Raises the height of the system while providing businesses with a convenient option for the storage of supplies and paper.
- Can only be configured with the standard configuration.
- Weight: 49.8 lbs. (18.5 kg)
- W x D x H (inches): 14.6 x 15.4 x 20.8
- W x D x H (mm): 371 x 391 x 528
Wireless Bridge Unit BR-500AC
ID: 423892
- An external wireless bridge that utilizes a cable connection to the Ethernet port on a MFP or printer.
Notes:
- 1. Requires an included AC adapter, so it does require a separate wall outlet.
- 2. This option does not offer Ad Hoc mode or Wi-Fi Direct capability.
PostScript3 Unit Type M34
ID: 418070
- Genuine Adobe® PostScript®3™. Recommended for printing more complex B&W and PDF files.
- The IM 305F, IM 430Fb and IM 430F come with standard PostScript3 Emulation and PDF Direct Print Emulation.
- This option is available for customers who require True Adobe® workflows like Photoshop®, Illustrator® and PDF/X as well as additional font support. When enabled on the MFP, the standard PostScript3 Emulation and PDF Direct Emulation will be disabled.
OCR Unit Type M13
ID: 417430
- This function embeds invisible text on scanned images of PDF and enables users to search PDF files by arbitrary keywords. Searchable PDF files can be sent to email, folders, and external media (USB/SD Card).
Optional Counter Interface Unit Type M12
ID: 417111
- 20-Pin interface used to attach external key counter or key card device.
