Display Touch Panel
Display Type
Liquid crystal display
Display Orientation
Landscape
Pixel Pitch
0.744 x 0.744 mm
Resolution
Maximum: 1,920 x 1,080 dpi
Viewing Angle HV
178°/178°
Brightness
Maximum: 360 cd/m²
Display Color
Maximum: Over 1.06 billion colors
Response Speed
8 ms (Grey to Grey, Ave.)
Panel Size
Diagonal: 65" wide (1,651mm)
Effective Display Area W x H
56.2" x 31.6" (1,428.5 x 803.5 mm)
Touch Sensor
Technology
Infrared touch
Operating System
Windows 7 Home Basic/Home Premium/Ultimate/Professional; Windows 8 and 8.1 Pro/Enterprise; Windows 10 Technical Preview; Windows Embedded Standard 7 P; Mac OS 10.6 and later
Accuracy
+/-10 mm in touchable areas
Touch Output
USB 2.0 (Type B)
Cover Glass
Pretreated anti-glare 4 mm thick
General
Weight
Less than 162.8 lbs. (74 kg)
Video Input
Display unit: Mini D-SUB15pin x 1, HDMI (HDCP x 2), HDMI (PC) x 1, DVI-D (HDCP x 1), DisplayPort (HDCP x 1), Composite x 1, Component x 1, S-Video x 1
Video Output
VGA x 1, DVI x 1, Composite x 1
Enhanced Features
Picture in Picture
Dimensions W x D x H
60.3" x 4.96" x 38.8" (1,531 x 126 x 885 mm)
Audio Output
Pin plugs (R+L) and terminals for 12W + 12W speakers
Other Features
Brightness will depend on input mode and other picture settings.
User Functions
20 color pen, Select, Delete (Erase), Undo/Redo, Save to USB/Network Folder/Interactive Whiteboard, Open PDF and PPT files from USB and Network Folder, Screen Page Select, Capture Page, Add New Page, Captured Page List, Delete Page, Copy Page, Marker Function, Auto Firmware Download
Remote sharing function
Up to 20 interactive whiteboards and projector systems
What's In the Box
Quick Guide and Safety Instruction, Warranty sheet, Customer registration postal card, RGB cable, USB cable. Power cord, Felt-tipped pen, Remote controller, AAA batteries (2)
Network Connection
Wired LAN: 10BASE-T/100BASET/ 1000BASE-T
Interfaces
USB 2.0 TYPE B x 1 for touch control
Power Source
100 - 240 V, 50/60 Hz
Environmental Data
Power Consumption
Less than 300W (with controller)
Operating Humidity
10% - 80%
Stand-by mode
Less than 12W (without controller)
Altitude limitation
Lower than 2,000m (sea level)
Operating Temperature
0°C - 32°C
